Beskrivning
Tillverkare: Sapphire
GPU RX 580, 14 nm FinFET
4th Graphics Core Next (GCN)
Engine Clock
Up to 1430 MHz, Boost
Stream Processors
2304
Memory Size/Bus
8GB GDDR5/256-bit
Memory Clock
8000 MHz effective
Displays
Maximum 5 Outputs
Resolution
DisplayPort: 5120×2880@60Hz
HDMI: 4096×2160@60Hz
DVI:2560x1600@60Hz
Interface
PCI-Express 3.0
Output
2x HDMI 2.0b
2x DisplayPort 1.4
1x DL-DVI-D
BIOS Support
Dual UEFI
API
OpenGL® 4.5
OpenCL 2.0
DirectX® 12
Shader Model 5.0
Game Index
1440p gaming
Sapphire Features
Blue shroud
NITRO Fan Check
NITRO Quick Connect System
NITRO Glow RGB LED
NITRO CoolTech(NCT)
Intelligent Fan Control III
Precision Fan Control
Robust VRM Cooling
Long Life Polymer Capacitor
Fuse Protection
Dual UEFI
AMD Features
Radeon™ VR Ready Premium
Radeon™ Software
Radeon™ FreeSync Technology
AMD LiquidVR™ Technology
4th Gen GCN Architecture
Radeon™ Chill
Radeon™ ReLive
DirectX® 12 Technology
AMD Eyefinity Technology (Gaming)
AMD App Acceleration
AMD CrossFire™ Technology
AMD CrossFire™ (Bridgeless)
3rd Gen 14nm Process Technology
OpenCL 2.0
OpenGL 4.5
AMD PowerTune Technology
TrueAudio Next
Unified Video Decoder (UVD)
Video Code Engine (VCE)
Virtual Super Resolution
The Vulkan® API
Cooler Type
Dual-X fans
Two ball bearing
Form Factor
2.2 Slots Occupied
260X135X43 Dimension/mm
Power Consumption
<235W
OS
Windows® 11, 10, Windows® 7
64bit operating system required
System Requirement
500 Watt or greater power supply (Recommended)
1 x 8-pin Power Connector + 1 x 6-pin Power Connector
PCI Express® compliant motherboard with one x16 graphics slot
